Description
Technical Data:
Swage Fork B3: Casting Material
AISI316 , EN 1.4408
Swage: Forging Material
AISI316 , EN 1.4401
Surface Treatment:
Electro polished / Passivated
MBL: Minimum Breaking Load before cable assembly
Limit Tension:
Recommended maximum load for a tension member.
All other applications should consider 1/4 of MBL
TAP: 23.1
DATA SHEET DOWNLOAD
Model
S7803_B3
Swage Fork B3
316 ss
| SS316 | SIZE ØCable (mm) | ØA (mm) | B (mm) | C (mm) | L (mm) | ØOD (mm) | Unit weight (kgs) | Limit Tension (kN) | MBL (kN) |
|---|---|---|---|---|---|---|---|---|---|
| 67803349 | 10 | 20 | 20 | 42 | 225 | 21.4 | 1.03 | 64 | 126 |
| 67803336 | 12 | 22 | 22 | 48 | 259 | 21.4 | 1.28 | 79 | 155 |
| 67803337 | 14 | 24 | 25 | 55 | 296 | 25 | 1.76 | 92 | 181 |
| 67803338 | 16 | 26 | 27 | 60 | 328 | 28.1 | 2.36 | 120 | 236 |
| 67803339 | 19 | 30 | 33 | 70 | 392 | 34.5 | 4.43 | 181 | 357 |
| 67803340 | 20 | 30 | 33 | 70 | 404 | 34.5 | 4.43 | 181 | 357 |
| 67803341 | 22 | 34 | 36 | 75 | 447 | 40.4 | 5.99 | 213 | 420 |
| 67803342 | 24 | 36 | 39 | 80 | 488 | 46 | 8.15 | 255 | 502 |
| 67803343 | 28 | 42 | 45 | 90 | 561 | 50 | 13.04 | 342 | 672 |
| 67803344 | 30 | 50 | 52 | 100 | 610 | 58 | 23.6 | 460 | 905 |
| 67803345 | 34 | 50 | 56 | 110 | 688 | 65 | 31.83 | 531 | 1,044 |
| 67803346 | 36 | 55 | 60 | 115 | 722 | 65 | 37.52 | 618 | 1,216 |
| SS316 | SIZE ØCable (mm) | ØA (inch) | B (inch) | C (inch) | L (inch) | ØOD (inch) | Unit weight (lb) | Limit Tension (kN) | MBL (kN) |
|---|---|---|---|---|---|---|---|---|---|
| 67803349 | 10 | 0.79 | 0.79 | 1.65 | 8.86 | 0.84 | 2.26 | 64 | 126 |
| 67803336 | 12 | 0.87 | 0.87 | 1.89 | 10.2 | 0.84 | 2.82 | 79 | 155 |
| 67803337 | 14 | 0.94 | 0.98 | 2.17 | 11.65 | 0.98 | 3.87 | 92 | 181 |
| 67803338 | 16 | 1.02 | 1.06 | 2.36 | 12.91 | 1.11 | 5.19 | 120 | 236 |
| 67803339 | 19 | 1.18 | 1.3 | 2.76 | 15.43 | 1.36 | 9.74 | 181 | 357 |
| 67803340 | 20 | 1.18 | 1.3 | 2.76 | 15.91 | 1.36 | 9.74 | 181 | 357 |
| 67803341 | 22 | 1.34 | 1.42 | 2.95 | 17.6 | 1.59 | 13.18 | 213 | 420 |
| 67803342 | 24 | 1.42 | 1.54 | 3.15 | 19.21 | 1.81 | 17.93 | 255 | 502 |
| 67803343 | 28 | 1.65 | 1.77 | 3.54 | 22.09 | 1.97 | 28.69 | 342 | 672 |
| 67803344 | 30 | 1.97 | 2.05 | 3.94 | 24.02 | 2.28 | 51.92 | 460 | 905 |
| 67803345 | 34 | 1.97 | 2.2 | 4.33 | 27.09 | 2.56 | 70.03 | 531 | 1,044 |
| 67803346 | 36 | 2.17 | 2.36 | 4.53 | 28.43 | 2.56 | 82.54 | 618 | 1,216 |
